Isuzu 450 D 2016 Manual
. Isuzu N series (USA, Canada, Mexico).
2018 Isuzu D-MAX SX (4x4) Manual 3.0L Crew C/Chas. Compare this car. Optional Features. Metallic Paint. 1999+ Aisin AW450-43LE 4 speed auto (w/gas engine) GM Hydramatic 4L80-E 4 speed auto 5/6 speed manual. The Isuzu Elf (Japanese: いすゞ・エルフ) is a medium duty truck produced by Isuzu since 1959. In 2016, it reintroduced the model as the Low Cab Forward (LCF) series, named. Jump up to: Nagayama, p. Click on the correct module number and a PDF of the instructions will automatically open in another. Isuzu NPR 6.0 2014-2018 ECOEMS950. Ford F250-550 6.7L Diesel 2011-2016 EMS503-D. All Other Vehicles PRN405-450.
Isuzu Grafter (United Kingdom). Isuzu Bison (Third Generation - Indonesia). QingLing QingXingShangYongChe (China). Isuzu Reward (various markets).
Chevrolet N series (Colombia, Egypt). Chevrolet W series. Chevrolet LCF series.
GMC Forward. GMC W series. UD Condor (Elf 6th Generation). (Elf 5th Generation/6th Generation).
(Elf 5th Generation/6th Generation). HICOM Perkasa (, 5th Gen). Isuzu Forward Juston (wide cab variant) Production 1959–present Assembly. Isuzu Elf first generation (1959-1965 model) The cab-over 2-tonne (4,400 lb) Elf (TL221) was originally introduced in August 1959. It was originally only available with the 1.5 litres (1,491 cc) GL150 petrol engine with 60 PS (44 kW). It had single headlights and rear-hinged doors. A longer wheelbase version, on 2,460 mm (97 in) versus the 2,180 mm (86 in) of the regular version, was also available.
This carries the TL251 chassis code. In March 1960 a 2-liter with 52 PS (38 kW) was introduced (TL121/151), a first for the class in Japan - this was soon followed by diesel models from Isuzu's competitors. In 1962 the engines were updated, and now have 72 and 55 PS (53 and 40 kW) respectively. The chassis codes were changed to TL321/351 for the diesel version, reflecting the installation of the all new engine.
A little later, the chassis codes were reorganized and were now TLG10/11 for the petrol models and TLD10/11 for the diesels. In 1964 the long wheelbase model became the standard version. In 1964 the diesel was also upgraded to the larger 2.2-litre C220 with 62 PS (46 kW). In 1965 the front was redesigned, now with twin headlights. Isuzu ended up offering a very wide variety of bodyworks for the first Elf.
There was the original integrated bed, as well as a separate truckbed with dropsides. There was a double-cab version available, as well as special bodywork for dedicated purposes such as a soda truck, a dumper, and a tanker.
There was also a 'Route Van' model with a glazed rear compartment and seating either three or six, as well as the 'Elf Bus' which was available in two models from 1960. The Elf Light Bus has integrated bodywork and the long wheelbase and seats 21 passengers (chassis codes BL171/271 for the diesel/petrol) while the Elf Micro Bus fit into the very narrow slot between the Route Van and the Light Bus. The Micro Bus originally had the Route Van's bodywork but was more passenger oriented (seating 12 or 15).
It carried the TL121/151/21/251B chassis codes, and from 1961 it received its own rear bodywork with bigger glazing. The Elf Bus later became its own line, called the.
KA50 Elf, in use as a in Thailand In August 1967 the all-new 'Isuzu Light Elf' was added to the existing lineup; this lighter duty version was rated for a 1.25-tonne payload (2,800 lb). It had single round headlights and a KA-series chassis code; it came with the same 1471 cc engine as fitted to period, providing 68 PS (50 kW).
This was the first of the second generation Elfs to be introduced, heavier duty models soon followed and replaced first generation variants. In April 1968 the second generation Elf appeared (TL21/TLD21 series).
A walk-through van ('Elf Hi-Roof') was also introduced, another first for Japan. In September 1969 the 'Light Elf' was upgraded to 1.5-tonne (3,300 lb) and now offered a more powerful 1.6-liter engine with 75 PS (55 kW). In October 1970 this part of the range became the Elf 150 while the regular Elf (2-2.5 tonnes) became the Elf 250; the 250 was updated to a 2.4-litre diesel engine. This was combined with the introduction of the heavier duty, 3.5-tonne (7,700 lb) Elf 350. This re-shake of the lineup was then followed by the very modern Elf Mi-Pack in April 1972.
The Mi-Pack was a front-wheel drive model with a flat and low loading floor, only 450 mm (18 in) off the ground. Because of its high price combined with customer reluctance to a front-wheel drive truck it was retired after only a few years on the market. Instead a low-floor model of the Elf 150 was added to the lineup in 1974, featuring small twinned rear tires. The heavier duty Elf 350 was not immediately replaced but continued in production until the 1980 model year, when in February a 350 model of the third generation Elf was introduced ('350 Wide'). Third generation Elf 250 Super, second facelift (1981-1984) The third generation Elf arrived in June 1975, in Elf 150 10 ft., Elf 150 14 ft. 6 wheel and Elf 250 forms are standard.
Isuzu 450 D 2016 Manual My15
It was nicknamed ' after 's (a famous Japanese actor) most beloved film character which supposedly looked similar. In January 1977 a 250 Low-Flat model was added, followed in 1978 by a facelift and an altered front grille. In 1979 a 3.3-liter 4BC1 engine of the 2-tonne (4,400 lb) Elf 250 and 350 wide was introduced, called the 'Elf 250 Super'. There was also a 'Elf 150 Super' version, has the 2.4-liter C240 diesel engine and The 2.8 liter 4BA1 engine for the Elf 150 14 ft. 6 wheel version and Elf 250 wide with heavy-duty transmission.which was usually installed in the Elf 250. In 1978 Isuzu also sold their millionth Elf.
In January 1980 the Elf was updated to meet Japan's 1979 emissions standards, which was also when the design was changed to accommodate a tilting cab. The Elf 250 Wide and 350 Wide were added, with KT and KS chassis codes respectiverly, meaning that the second generation Ef 350 could finally be retired. The Elf Wide has a cabin 1,910 mm (75 in) wide, rather than the 1,690 mm (67 in) cabin used in the TL and KA-series Elfs. In 1981 the Elf 150/Elf 150 14 ft. And Elf 250 are standard using the 4BA1 engine and 4BC1 for the Elf 350 wide. Range underwent another facelift, with an updated dashboard as well. For the third generation Elf the diesel engines had been modernized for more ease of operation, while the world's then smallest direct injection diesel engine - the 3.3-liter - was also introduced.
It arrived in 1982 and replaced the less powerful 4BC1 which had appeared in 1979. In March 1983 the diesel engines were again modified, reflecting new Japanese emissions standards for commercial vehicles. While the third generation Elf was mostly replaced in 1984, the 'Route Van' (three- or six-seater van version) continued in production until the early 1990s. With the same bodywork there was also a more habitable bus version available; this was marketed as the and was built on Elf 150 basis (KAD51ZB). Chassis codes code engine output models PS kW at (rpm) KA41/51, petrol 1584 cc Elf 150 KAD41/51, I4 1951 cc Elf 150, Journey S KAD42/52, TLD23, diesel I4 2369 cc Elf 150 Super, Elf 250 TLD24/34/44/54/64, diesel I4 2775 cc Elf 250 TLD55, diesel I4 3268 cc Elf 250 Super TLD26/36/56, KT26/36/46, diesel I4 1 Elf 250 Super, Elf 250 Wide KS, diesel I4 3856 cc 110 81??00 Elf 350 Wide.
Honda 110cc engine parts manual. 1990-1993 Isuzu Elf 250 Wide double-cab The fourth generation Elf range appeared in July 1984. This Elf was exported widely across the world and manufactured in several different countries, including the United States. It was sold as the Chevrolet Tiltmaster, and also as the GMC Forward. GMC's Forward replaced their L series and has a 165 hp (123 kW) turbodiesel. It was also the first model to use the long-running Isuzu N-series label.
In 1986 a heavier duty 220 hp (164 kW) 8.4-litre diesel version of the Forward was added to the US market. In Japan this generation was only offered with direct injection diesel engines, introducing the new 2.8-liter 87ps family industrial version with dual mode transmission depending in application.and the 3.6-liter 4BE1 direct injection engine for the Elf 250 and Elf 350 NPR. Which replaced the long running 4ba1 as the standard Elf 150 10 ft. And Elf 150 14 ft.
In September 1987 a 16 ft. Heavier version Elf 350 wide has arrived. With The long stroke direct injection with dual mode manual transmission 3.9-liter 4BD1 and 4BD1 turbo diesel engine and the four-wheel drive version of the Elf 250 was introduced, this was originally only available with the 110 PS (81 kW). The fourth Elf/N series originally had twin rectangular headlamps and a grille with five separate segments (seven for the Wide Cab models).
In February 1987 a facelifted version with a grille of only two larger segments appeared, at which time the engine lineup was also altered. This was followed by a second facelift in June 1990, after which the grille became a single. Lower opening and the headlights were changed to more aerodynamic, single-piece units. This model was also manufactured in China, by (Beijing Light Automobile Corporation) from 1984 until 2002. Later it was also built by, a subsidiary of Guangzhou.
After a company reorganization it has been built by them as the Guangzhou Hino 300J (YC5040XXY) since 2008, with a redesigned front and various other improvements. Elf 250, earlier model The fifth generation Isuzu Elf appeared in July 1993, with more sculpted headlights. The 2.8 4JB1 and 4JB1T are standard on both Elf 150 10 ft/14 ft. And Elf 250 along with 3.6 4BE1. The non turbo 4JB1 features a new VE Rotary injection pump which increase power to 90ps and euro emission.
In May 1995 it received a minor change, including upgraded, cleaner diesel engines.The H-series 4.0-liter 4HE1 and 4.3-liter 4HF1. Chassis with H-series engine are standard while the 14 ft. Version are still in production.
OEM deal with Nissan led to the Elf also being sold badged as a and a Nissan Diesel Condor 20/30/35 beginning at this time, followed by the Nissan Atlas Max from 1996 until 2000. The Atlas Max was based on the new, lighter duty Elf 100 (June 1995) which was available with a 2-liter petrol or a 2.5 or 2.7-liter diesel engine. The elf was marketed as the Isuzu NPR and Chevrolet/GMC W series, each available with either the 4HE1 4.8-liter turbocharged diesel engine or GM's L31 Vortec 5.7-liter gas engine and 4L80-E Automatic Transmission. The gas engine produced 275 hp (205 kW) to 325 hp (242 kW) at 4600 rpm and 330 lbft (447 Nm) to 350 lbft (475 Nm) of torque at 2800 rpm.
In May 2004, subsequent to a few minor changes, the Elf underwent a more major facelifts with new, larger, trapezoidal headlamps. Another OEM deal was forged at this time and the Elf was now also marketed as a in parallel. In, this truck is manufactured by under the name of HICOM Perkasa, but carrying the Isuzu N-Series Commando badge. Sixth generation. Isuzu NPS 300, The sixth generation Elf/N series was released in December 2006 (High Cab and Wide Cab) and February 2007 (Regular Cab). By the time the full range was available, the fifth generation Elf was retired. This was also assembled in Colombia (alongside the heavier F series), where it was sold as the Chevrolet NKR, NPR, or NQR.
GM began assembling Isuzu trucks in Chile in 1984. The headlight-turnsignal cluster is now configured in the shape of the Isuzu ', which was used from 1974-1991. In North America, GM sold the Isuzu N series as the Chevrolet and GMC W series until 2009.
In 2016, it reintroduced the model as the Low Cab Forward (LCF) series, named simply the Chevrolet 3500, 4500, or 5500, and available with the same gasoline or diesel engines. The design of the 6th-generation Isuzu Elf cabin bears some resemblance to an all-fiberglass cabin fitted to trucks made by the Brazilian company since 2003. Agrale introduced an all-steel Chinese copy of the Isuzu wide cab to its truck range in late 2015, but the fiberglass cab was not phased out. Nomenclature The Elf is sold as an Elf in some markets aside from the domestic Japanese, such as Mexico and Indonesia, but in most export markets it is called the Isuzu N series.
The second letter denotes weight rating, with H and K being used for the regular cab, M for the High Cab, and P, Q, and R for the Wide Cab model. The third letter denotes drivetrain layout; here an R means rear-wheel drive while S signifies four-wheel drive. See also. References.
